Mr. Welagen, how'd ya do it?

Gaz · Post by **Gaz** » Tue Feb 28, 2012 2:59 am

If you don't mind, I was wondering if you could tell me how you mounted the radials in this picture?

http://i608.photobucket.com/albums/tt16 ... DSguts.jpg

It looks like you just drilled two small holes for the leads, but I'm not sure if there's anything going on to keep them solid.

Pleeeeeeeeeeease?

Thanks!

jon · Post by **jon** » Tue Feb 28, 2012 3:10 am

Jelle, I'll answer this...

...solder

jelle · Post by **jelle** » Tue Feb 28, 2012 4:52 am

Eyelets, solder and some rtv....

Gaz · Post by **Gaz** » Tue Feb 28, 2012 8:23 am

Thanks, Jelle! Yeah, I still can't see the eyelets, but I believe you

Good to know you put some RTV to hold em down - I'm always looking for ways to make radials work in 'PTP' layouts, and the PS board in your amp looks really slick. Thanks again.

qtone · Post by **qtone** » Tue Feb 28, 2012 9:46 am

Fantastic wiring ..looking forward to owning one.
Nice Work Jelle

ToneMerc · Post by **ToneMerc** » Tue Feb 28, 2012 11:37 am

Gaz wrote:Thanks, Jelle! Yeah, I still can't see the eyelets, but I believe you

Maybe Jelle does it the way I've done it, using both 3/32 and 1/16 eyelets.

TM

boldaslove6789 · Post by **boldaslove6789** » Tue Feb 28, 2012 4:09 pm

Indeed Jelle, your amps are clean enough to eat off of. (of course nevermind the extremely Toxic Lead Solder, LOL, I know...)

NickC · Post by **NickC** » Tue Feb 28, 2012 4:17 pm

Gaz wrote:If you don't mind, I was wondering if you could tell me how you mounted the radials in this picture?

http://i608.photobucket.com/albums/tt16 ... DSguts.jpg

It looks like you just drilled two small holes for the leads, but I'm not sure if there's anything going on to keep them solid.

Pleeeeeeeeeeease?

Thanks!

I like modern Art.

Looking at that photo ..... it seems a shame to enclose that amp where folks can't see the beauty of it. I've seen a lot of such photos here at TAG. Magnificent and beautiful builds! Art with a capital "A"!

jelle · Post by **jelle** » Wed Feb 29, 2012 4:37 pm

ToneMerc wrote:
Gaz wrote:Thanks, Jelle! Yeah, I still can't see the eyelets, but I believe you
Maybe Jelle does it the way I've done it, using both 3/32 and 1/16 eyelets.

TM

Actually, that is an older amp, one I did a while ago. I only had the larger eyes to work with then. I have changed and cleaned up the layout quite a bit for the current ones.

Please see:
https://tubeamparchive.com/viewtopic.ph ... highlight=

Have fun,

Jelle

Structo · Post by **Structo** » Wed Feb 29, 2012 4:58 pm

Hope you don't mind but I was snooping in your photo gallery and saw this amp.
The white suede and silver chassis really looks cool

[IMG:614:1023]http://i608.photobucket.com/albums/tt16 ... en_amp.jpg[/img]

brentm · Post by **brentm** » Wed Feb 29, 2012 5:25 pm

jelle wrote: Actually, that is an older amp, one I did a while ago. I only had the larger eyes to work with then. I have changed and cleaned up the layout quite a bit for the current ones.

Please see:
https://tubeamparchive.com/viewtopic.ph ... highlight=

Have fun,

Jelle

Indeed, your standards and workmanship is impeccable! I do have one question if you don't mind... I'm curious why the preference to mount the octal tube sockets from the bottom of the amp vs from the top of the amp. I've seen it both ways and was just curious from an experienced builder as to the reason for this.

When I was playing around with my chassis, I noticed a tiny gap around the base of the socket when I mounted them from bottom. I reversed it and mounted them from inside the amp, and it seems to give a cleaner look outside of the amp... with the socket being flush with the bottom of the chassis.

jelle · Post by **jelle** » Mon Mar 05, 2012 3:34 pm

brentm wrote:
jelle wrote: Actually, that is an older amp, one I did a while ago. I only had the larger eyes to work with then. I have changed and cleaned up the layout quite a bit for the current ones.

Please see:
https://tubeamparchive.com/viewtopic.ph ... highlight=

Have fun,

Jelle
Indeed, your standards and workmanship is impeccable! I do have one question if you don't mind... I'm curious why the preference to mount the octal tube sockets from the bottom of the amp vs from the top of the amp. I've seen it both ways and was just curious from an experienced builder as to the reason for this.

When I was playing around with my chassis, I noticed a tiny gap around the base of the socket when I mounted them from bottom. I reversed it and mounted them from inside the amp, and it seems to give a cleaner look outside of the amp... with the socket being flush with the bottom of the chassis.

Good question....... For me it is a preference thing, plus it looks cleaner inside the chassis.

jelle · Post by **jelle** » Thu Mar 08, 2012 6:12 am

Structo wrote:Hope you don't mind but I was snooping in your photo gallery and saw this amp.
The white suede and silver chassis really looks cool

No worries and thanks!

Here's another one I have been working on, anodized chassis and silkscreened. HRM with loop, 100W from 4x 6L6CG:
[IMG

768]http://i608.photobucket.com/albums/tt16 ... Front1.jpg[/img]

[IMG

768]http://i608.photobucket.com/albums/tt16 ... /Rear2.jpg[/img]

[IMG

768]http://i608.photobucket.com/albums/tt16 ... Front3.jpg[/img]

qtone · Post by **qtone** » Thu Mar 15, 2012 3:36 am

Edited.... contacted..
